Push-Pull type toggle clamps

Straight Line Action Clamps

Push Pull toggle clamps or Straight Line Action Clamps use a plunger mechanism to produce a positive straight-line action. They lend themselves to pull or push plates, workpieces or components for squeezing them together. They are also used to fix or position slim components vertically.
We offer a wide selection of push-pull type toggle clamps, such as in a flat, compact design, with or without an angled base, in heavy-duty, precision, or stainless-steel versions. Some models can be supplied with an optional safety lock.

Push-Pull type toggle clamps product overview

Push-Pull type toggle clamp

low profile

Mini/low type

very low profile, flat base
Item group 113.300

Push-Pull type toggle clamp

various types and sizes

with horizontal base

horizontal mounting base
various types and holding forces

Push-Pull type toggle clamp

Threaded Body

DST-362 series

Holding capacity 910N up to 3180N
Item group 113.000

Push-Pull type toggle clamp

with fastening thread

M61

front/nose mounted type
Holding capacity 1.0kN bis 4.0kN

Push-Pull type toggle clamp

with small angle base

M60

with small angle base
Holding capacity 0.8kN bis 4.5kN

Push-Pull type toggle clamp

with safety latch

M60S

with safety latch
Holding capacity 2.5kN

Push-Pull type toggle clamp

with vertical base

M60D

with vertical mounting base
Holding capacity 0.8kN bis 4.5kN

Push-Pull type toggle clamp

flanged base

M60DS

with safety latch
heavy duty type

Push-Pull type toggle clamp

phosphated body

DST-30240/30450 series

Holding capacity 2500N up to 4500N
Item group 113.100

Push-Pull type toggle clamp

cast body

DST-30240/30450 series

cast varnished body
Holding capacity 2230N up to 6670N

Straight Line Action Clamps

with safety lock

M65S

push-pull clamp with safety lock
Holding capacity 2.7kN

Straight Line Action Clamps

with safety lock

DST-36015-T

push-pull clamp with safety lock
Holding capacity 2550N

Push-Pull type toggle clamp

with robust handle

M62

flat base, with handle
Holding capacity 2kN to 4kN

Push-Pull type toggle clamp

cast iron body

M64

cast iron lacquered body
Holding capacity 4kN up to 25kN

Push-Pull type toggle clamp

heavy duty type

M66

Heavy push-pull clamp
Holding capacity 7kN up to 12kN

Push-Pull type toggle clamp

heavy duty type

M66C

with reversible lever
Holding capacity 7kN uo to 12kN

Push-Pull type toggle clamp

heavy duty type

M66K

with square plunger
Holding capacity up to 12kN

Push-Pull type toggle clamp

heavy duty precision type

M68

heavy duty weldable type
Holding capacity from 15kN

Push-Pull type toggle clamp

heavy duty precision type

DST-30 Series

heavy duty weldable type
High holding forces 11kN to 22.7kN

Push-Pull type toggle clamp

M-SERIES

M-SERIES

Various available types
Download PDF-File
