Mini Push-Pull toggle clamp
Holding capacity : 400N
- very low profile
- acting through counter-clockwise rotation
DST 301-CL
- acting through counter-clockwise rotation
DST 301-CL
Mini Push-Pull toggle clamp
Holding capacity : 400N
- very low profile
- acting through clockwise rotation
DST 301-CR
- acting through clockwise rotation
DST 301-CR
In this series there are 15 available types of low profile push-pull type clamps :
| Modell-Nr. | Holding capacity (N) | Weight (g) | Handle Opens | Length (mm) | Height (mm) | Plunger height (mm) | Plunger Stroke (mm) | Material |
|---|---|---|---|---|---|---|---|---|
| DST-301-AM | 450 | 50 | 190° | 68 | 40 | 12.7 | 16.7 | Steel |
| DST-301-BM | 450 | 50 | 190° | 68 | 40 | 12.7 | 16.7 | Steel |
| DST-301-AMSS | 450 | 50 | 190° | 68 | 40 | 12.7 | 16.7 | |
| DST-301-CL | 400 | 56 | 190° | 75 | 17 | 10.5 | 16.4 | Steel |
| DST-301-CR | 400 | 56 | 190° | 75 | 17 | 10.5 | 16.4 | Steel |
| DST-302-FM | 1360 | 300 | 180° | 140 | 78 | 24.6 | 32.0 | Steel |
| DST-302-FMSS | 1360 | 300 | 180° | 140 | 78.0 | 24.6 | 32 | |
| DST-302-DM | 1600 | 454 | 45° | 220 | 50 | 21.5 | 12.0 | Steel |
| DST-302-DMSS | 1600 | 454 | 45° | 220 | 50 | 21.5 | 12.0 | |
| DST-30282-M | 1600 | 454 | 45° | 220 | - | 43.0 | 12.0 | Steel |
| DST-30290-M | 3000 | 1270 | 45° | 319 | - | 24.0 | 23.0 | Steel |
| DST-30292-M | 3000 | 1270 | 45° | 130 | 82 | 24.4 | 23.0 | Steel |
| DST-36006 | 500 | 64 | 93° | 64 | 67 | 15.5 | 13.0 | Steel |
| DST-36060 | 3000 | 690 | 76° | 300 | 56 | 43.0 | 28.0 | Steel |
| DST-360670 | 500 | 100 | 66° | 126 | 23 | 15.5 | 10.0 | Steel |
